Product Details:

Place of Origin: Shenzhen,China
Brand Name: Sinoseen
Certification: RoHS
Model Number: SNS-1MP-OV9782-V1.0

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: Tray+Anti-static bag in carton box
Delivery Time: 2-3weeks
Payment Terms: T/T
Supply Ability: 500000 pieces/month
Get Best Price Contact Now

Detail Information

Type: USB Camera Module Sensor: 1/4" Omnivision OV9782 CMOS Sensor
Resolution: 1MP 1280(H) X 720(V) Dimensions: 38mmx38mm (customizable)
Lens FOV: 90°(optional) Focus Type: Fixed Focus
Interface: USB2.0 Feature: Global Shutter
High Light:

1MP USB Camera Module

,

CMOS USB Camera Module

,

1MP usb camera module

Product Description

Global Shutter CMOS USB2.0 Imaging Camera Module 1MP Color Image

Global Shutter Color Image wifi infrared thermal USB 2.0 Camera Module with OV9782 sensor



USB2.0 Camera Module

This is a very good color image global exposure USB camera module. It has the 1MP (1280x800) resolution with Omnivision OV9782 CMOS sensor, and the image quality is very high and stable.

OmniVision's OV9782 is a high-speed global shutter image sensor that can bring a variety of consumer and industrial computer vision applications (including augmented reality (AR), virtual reality (VR) and UAV collision avoidance, barcode scanning and factory automation). Resolution of megapixels. OV9782 is based on OmniVision's OmniPixel3-GS pixel technology, with high-speed global shutter pixels, first-class near infrared (NIR) quantum efficiency (QE), and can meet the requirements of high resolution and low latency.

This global shutter color image usb camera module can be widely used in many high-tech high-end applications, such as robotics, robotics, machine vision, industrial automation, vision systems, imaging, automobiles, object tracking, factory automation, medical equipment, artificial intelligence, augmented reality (AR), Virtual reality (VR), computer vision, drones, sports, agriculture, barcode scanning and 3d, etc.





Specification

Model No

SNS-1MP-OV9782-V1.0
Sensor
1/4’’ Omnivision OV9782 CMOS sensor
Pixel
1 Mega Pixel
Most effective pixels
1280(H) x 720(V)
Pixel Size
3.0µm x 3.0µm
Image area
3896µm x 2453µm
Chroma
COLOR Image
Compression format
MJPG/YUY2
Resolution & Frame rate
See above
Shutter Type
Global shutter
Focus type
Fixed focus
S/N ratio
38dB
Dynamic range
68dB
Protocol
Plug-&-Play (UVC compliant)
Interface type
USB2.0 high speed
Lens
Lens Size: 1/4 inch
FOV: 90°
Thread Size: M12*P0.5
Audio frequency
Optional
Power supply
USB BUS POWER
Power consumption
DC 5V, 180mW
Main chip
DSP/SENSOR/FLASH
Auto Exposure Control
Not supported
Auto White Balance
Supported
Auto Gain Control
Not supported
Dimension
38mm*38mm
Storage temperature
-20°C to 70°C
Operating temperature
0°C to 60°C
USB cable length
Default
Adjustable parameter
Brightness/Contrast/Color saturation/Hue/
Definition/Gamma/White balance
Support OS
WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
Global Shutter CMOS USB2.0 Imaging Camera Module 1MP Color Image 0Global Shutter CMOS USB2.0 Imaging Camera Module 1MP Color Image 1



Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request





Current avaliable global shutter USB camera module





Omnivision                       OV7251        0.3MP         Monochrome(black and white)



Omnivision                       OV9281           1MP         Monochrome(black and white)



ON Semiconductor          AR0144            1MP         Monochrome(black and white) or RGB color



Omnivision                      OG02B1B         2MP         Monochrome(black and white)



Omnivision                      OG02B10          2MP        RGB color
