High Sensitivity Full HD 1080P HDR MIPI Camera Module OEM Low Power Consumption
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-2MP-PS5268-M1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | 1/2.7" PrimeSensor PS5268 |
|---|---|---|---|
| Resolution: | 2MP 1928(H) X 1088(V) | Dimensions: | Customizable |
| Lens FOV: | 100°(optional) | Focus Type: | Fixed Focus |
| Interface: | MIPI | Feature: | HDR |
| High Light: | Low Power Consumption MIPI Camera Module,1080P HDR MIPI Camera Module,High Sensitivity OEM Camera Modules |
||
Product Description
High Sensitivity OEM Camera Modules Full HD 1080p HDR Auto Exposure
OEM Low Power Consumption High Sensitivity Full HD 1080P HDR MIPI Camera Module
Camera Modules Full HD 1080P
This OEM Low Power High Sensitivity Full HD 1080P HDR MIPI Camera Module is a camera module specially designed for applications where low power consumption and high sensitivity are important. MIPI (Mobile Industry Processor Interface) is a standard interface for connecting cameras and processors in mobile devices, and the camera module is designed to be compatible with the MIPI interface.
The camera module features a high-sensitivity image sensor that can capture images in low-light conditions, making it ideal for applications where lighting can be challenging. It also has a Full HD 1080P resolution for high-quality images and videos with excellent detail and clarity. The HDR feature allows the camera to capture images with a wider dynamic range, meaning it can capture bright and dark areas of an image in greater detail and more accurately.
The low power consumption of this camera module makes it ideal for use in battery-operated devices such as cell phones or camcorders, where minimizing power consumption is important.
Specification
|
Module No |
SNS-2MP-PS5268-M1 |
|
Pixel Size |
3.0μm x 3.0μm |
|
Effective Pixels |
1928H×1088H |
|
Video output |
Raw Bayer10bit/8bit |
|
Active Array Size Video Rate |
1080p: 1920x1080 @ 60fps 1080p: 1920x1080 HDR-LTM @30fps |
|
Image Sensor |
1/2.7" |
|
Sensor Type |
PrimeSensor PS5268 |
|
Lens view |
FOV100°(optional),F/N(optional) |
|
TV Distortion |
<1% |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Operating voltage |
Analog: 3.3 V Digital: 1.2 V I/O: 1.8V / 3.3V |
|
Operating temperature |
-30～85℃ |
|
Storage temperature |
-20～70℃ |
|
Dimensions |
Customizable |
