Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor

Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor

Product Details:

Place of Origin: Shenzhen,China
Brand Name: Sinoseen
Certification: RoHS
Model Number: SNS-8MP-3H7-V1.0

Payment & Shipping Terms:

Minimum Order Quantity: 3
Price: negotiable
Packaging Details: Tray+Anti-static bag in carton box
Delivery Time: 2-3weeks
Payment Terms: T/T
Supply Ability: 500000 pieces/month
Get Best Price Contact Now

Detail Information

Type: USB Camera Module Sensor: 1/3.2" Samsung S5K3H7
Resolution: 8MP (3264*2448) Dimensions: Customizable
Lens FOV: 90°(optional) Focus Type: Fixed Focus
Interface: USB2.0 Feature: 4K
High Light:

S5K3H7 Uhd Camera Module

,

4K Uhd Camera Module

,

S5K3H7 Camera Module 4K

Product Description

Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor

8MP USB2.0 Camera Module with Samsung 3H7 Cmos sensor UVC Compliant drive free



This is one of our 4K camera module, it is 8MP (3840x2160) resolution with Samsung 3H7 CMOS sensor, image quality is quite excellent and stable. The biggest advantage of this camera module is that it supports 30FPS high frame rate at full resolution 8MP (3840x2160), while most of other 8MP sensor can only support 15FPS frame rate at 8MP!


Specification

Model No
SNS-8MP-3H7-V1.0
Sensor
1/2.5’’ Samsung 3H7 CMOS
Pixel
8 Mega Pixel
Most effective pixels
3264(H) x 2448(V)
Pixel Size
1.4µm x 1.4µm
Image area
3864um (H) x 2196um (V)
Compression format
MJPEG / YUV2 (YUYV)
Resolution & Frame rate
See above
Shutter Type
Electronic rolling shutter
Focus type
Fixed focus
Chroma
Color, RGB
Clock Frequency
6 to 72 MHz
Microphones
Built-in
Interface type
USB2.0
Adjustable parameter
Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure


Lens
Focal length: 3.6mm
Lens construction: 5E+IR
H FOV: 90 degree
Thread Size: M12*P0.5
Audio frequency
Optional
Power supply
USB BUS POWER
Operating Voltage
DC 5V
Operating Current
260mA
Main chip
DSP/SENSOR/FLASH
Auto Exposure Control  (AEC)
Support
Auto White Balance (AEB)
Support
Auto Gain Control (AGC)
Support
Dimension
Customizable
Storage temperature
-20°C to 70°C
Operating temperature
0°C to 60°C
USB cable length
Default


Support OS
WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC



Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor 0Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor 1



Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request





FAQ:


Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.


Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.


Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.


Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.


Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
