4K High Dynamic Range HDR 8MP Wide Angle Lens USB Camera Module With SONY IMX415 Sensor
Product Details:
Place of Origin: | Shenzhen,China |
Brand Name: | Sinoseen |
Certification: | RoHS |
Model Number: | SNS-GM868M-V1 |
Payment & Shipping Terms:
Minimum Order Quantity: | 3 |
---|---|
Price: | negotiable |
Packaging Details: | Tray+Anti-static bag in carton box |
Delivery Time: | 2-3weeks |
Payment Terms: | T/T |
Supply Ability: | 500000 pieces/month |
Detail Information |
|||
Type: | USB Camera Module | Sensor: | 1/2.8"SONY IMX415 |
---|---|---|---|
Resolution: | 8MP (3840*2160) | Dimensions: | 38x38mm (customizable) |
Lens FOV: | 100°(optional) | Focus Type: | Fixed Focus |
Interface: | USB2.0 | Feature: | HDR |
Highlight: | SONY IMX415 Sensor Camera Module,8MP USB2.0 Camera Module,4K HDR 8MP Camera Module |
Product Description
4K High Dynamic Range 8MP Camera Module Wide Angle Lens IMX415 Sensor
4K High Dynamic Range HDR 8MP Wide Angle Lens USB Camera Module With SONY IMX415 Sensor
8MP Camera Module
This 4K High Dynamic Range (HDR) 8MP Wide Angle Lens USB Camera Module with SONY IMX415 Sensor is a high performance camera module designed for a range of applications requiring high quality image capture. The module has 8MP resolution and can capture video at 4K resolution, making it ideal for use in applications where high-quality images are critical.
One of the key features of the SONY IMX415 sensor is its high dynamic range, which enables the camera to capture images with a high level of detail in both bright and dark areas of the scene. This makes it ideal for applications where lighting conditions may vary, such as surveillance or outdoor photography.
The camera module is also equipped with a wide-angle lens with a wider field of view, making it easier to capture images of large areas or objects. This makes it ideal for applications such as video conferencing or surveillance.
In addition to high image quality, the camera module features a USB interface for easy connection to a computer or other device for image processing and analysis. Its compact size and plug-and-play design allow easy integration into various systems and devices.
Model No |
SNS-GM868M-V1 |
Sensor |
1/2.8’’ SONY IMX415 CMOS |
Pixel |
8 Mega Pixel |
Most effective pixels |
3840(H) x 2160(V) |
Pixel Size |
1.45µm x 1.45µm |
Image area |
3864um (H) x 2196um (V) |
Compression format |
MJPEG / YUV2 (YUYV) |
Resolution & Frame rate |
See above |
Shutter Type |
Electronic rolling shutter |
Focus type |
Fixed focus |
Chroma |
Color, RGB |
Clock Frequency |
6 to 72 MHz |
Microphones |
Built-in |
Interface type |
USB2.0 |
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure |
Lens |
Focal length: 3.6mm |
Lens construction: 5E+IR |
|
D FOV: 100 degree |
|
Thread Size: M12*P0.5 |
|
Audio frequency |
Optional |
Power supply |
USB BUS POWER |
Operating Voltage |
DC 5V |
Operating Current |
260mA |
Main chip |
DSP/SENSOR/FLASH |
Auto Exposure Control (AEC) |
Support |
Auto White Balance (AEB) |
Support |
Auto Gain Control (AGC) |
Support |
Dimension |
38MMx38MM Customizable |
Storage temperature |
-20°C to 70°C |
Operating temperature |
0°C to 60°C |
USB cable length |
Default |
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
Current available USB solution
0.3MP
Low cost:BF3703 BF2103 GC0329 GC0309 GC0307 GC032A OV7675
Big size:GC0308(1/6.5”) GC0328(1/6.5”) GC0403(1/3”-0.4MP) BF3A03(1/6.5”)
Global shutter:OV7251 (1/7.5”,B/W)
High frame rate:200FPS SC031GS(1/6”,B/W)
Big size with high frame rate: OV7725(1/4”,60FPS),OV7740(1/5”,60FPS)
1MP
Low cost:GC1024 GC1034 GC1064(H264) H42 H62 SP1405 OV9712 OV9732 NT99141 SC1245 OV9760
Small size for endoscope:OV9734 GC1009 HM1091
Global shutter:OV9281(1/4”,B/W) OV9782(1/4”,color) AR0144(1/4”,color) AR0135(1/3”,color)
Big size (30FPS):AR0130(1/3”,B/W) OV10635(1/2.7”,color,WDR,960P) H65(1/3”,color,960P)
2MP
Normal(10FPS):GC2145(1/5”) BF2206(1/5”)GC2335 OV2643 HM2056 BF3925 OV2755(1/5” HD)
1080P low cost:F23 F37 F35 SP2305 GC2053 GC2023 AR0330(300W) SC2232H C2390 IMX322 C2395 SC2315 AR0237
1080P small size (30FPS):OV2732(1/4”) OV2740(1/4”) OV2722(1/6”) SC2145(1/4”) HM2160(1/6”)
1080P@60FPS:OV2710 HM2131 IMX307 C2395 SC2315 F35 SC2310
1080P-HDR (30FPS): OV2735 OV2718 PS5268 IMX307
1080P-WDR (30FPS): AR0230 AR0331(300W)
1080P-Starvis (30FPS): IMX291 IMX307 IMX323 IM290
1080P big size: IMX385
1080P global shutter: OG02B10(color) OG02B1B(B/W)
5MP
500W (15FPS): OV5648 GC5025 OV5640 OV5643 OV5693(up to 30FPS) 4EC OV5650
FHD 500W(30FPS): OS05A10 PS5520 HM5532 MI5100 MT9P001 IMX335 SC5335 AR0521 JXK05 OV4689(2K,1/3”)
8MP
800W (15FPS): IMX219(1/4”)S5K3H7 IMX179 C8390
8M-4K UHD (30FPS): IMX317 IMX415 OS08A10(big size 1/1.8”)
13MP-16MP
IMX214(13M) IMX258(13M) IMMX298(16M)
USB3.0
IMX335 OV5648 IMX179 IMX307 PS5268
H264
GC1064 OV2710 OV2735 OV9732 AR0130 AR0230 AR0330 H65 H62 IMX291 IMX322 IMX323 OV2718 OV2732
