OV7251 Sensor FPC Global Shutter Camera Module MIPI CIS Interface
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-OV7251-M1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | 1/7.5" Omnivision OV7251 |
|---|---|---|---|
| Resolution: | 0.3MP (640*480) | Dimensions: | 50*8.5mm (Customizable) |
| Lens FOV: | 55°(optional) | Focus Type: | Fixed Focus |
| Interface: | MIPI | Feature: | Global Shutter |
| High Light: | 0.3MP OV7251 Global Shutter Camera Module,0.3MP FPC Global Shutter Camera Module,ov7251 camera module |
||
Product Description
OV7251 Sensor FPC Global Shutter Camera Module MIPI CIS Interface
Global Shutter MIPI CIS Interface FPC 0.3MP 120FPS Camera Module With OV7251 Sensor
This is a 0.3MP global shutter MIPI camera module with the sensor OV7251 from Omnivision.It has below features:
3 µm x 3 µm pixel with OmniPixel3-GS™ technology
automatic black level calibration (ABLC)
programmable controls for frame rate, mirror and flip,
cropping and windowing
support output formats: 8/10-bit RAW
support for image sizes: 640x480, 320x240, 160x120
fast mode switching
supports horizontal and vertical 2:1 and 4:1
monochrome subsampling
supports 2x2 monochrome binning
one-lane MIPI serial output interface
one-lane LVDS serial output interface
embedded 256 bits of one-time programmable (OTP)
memory for part identification
two on-chip phase lock loops (PLLs)
built-in 1.5V regulator for core
PWM
built-in strobe control
This camera module is widely used in cellular phones,digital still cameras (DSC),digital video ,camcorders (DVC),PC multimedia,tablets,etc.
Specification
|
Pixel Size |
3.0μm x 3.0μm |
|
Effective Pixels |
640*480 |
|
Image Sensor |
1/7.5" |
|
Sensor Type |
OV7251 |
|
Lens View |
FOV55°(Optional),F/N(Optional) |
|
TV Distortion |
<1% (Optional) |
|
Temperature(Operation) |
0～60℃ |
|
Temperature(Storage) |
-20～70℃ |
|
Dimension |
50*8.5mm (Customizable) |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
Current avaliable global shutter USB camera module
Omnivision OV7251 0.3MP Monochrome(black and white)
Omnivision OV9281 1MP Monochrome(black and white)
ON Semiconductor AR0144 1MP Monochrome(black and white) or RGB color
Omnivision OG02B1B 2MP Monochrome(black and white)
Omnivision OG02B10 2MP RGB color
