Low Light Performance 13MP Camera Module OV13850 Sensor For Smartphones
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-131128-V1.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | Omnivision OV13850 |
|---|---|---|---|
| Resolution: | 13MP 4224(H) X 3136(V) | Dimensions: | Customizable |
| Lens FOV: | 90°(optional) | Focus Type: | Auto Focus |
| Interface: | MIPI | Feature: | Low Light Performance |
| High Light: | ov13850 13MP Camera Module,13MP MIPI Camera Module,MIPI ov13850 camera module |
||
Product Description
Low Light Performance 13MP Camera Module OV13850 Sensor For Smartphones
Low Light Performance 13MP MIPI Camera Module With Omnivision OV13850 For Smartphones And Tablets
13MP Camera Module OV13850
This is a low Light Performance 13MP MIPI Camera Module With Omnivision OV13850 For Smartphones And Tablets,The OV13850 is a high performance PureCel™13-megapixel CameraChip™ sensor that deliversbest-in-class high- and low-light performance, as well as dramatically reduced power consumption for smartphones and tablets. The OV13850 sensor offers a number of performance enhancements, including improved full-well capacity (FWC) and sensitivity for industry-leading high- and low-light performance.
It also offers a 40 percent reduction in power consumption compared to our previous generation sensor, making the OV13850 ideally suited for feature-rich mobile devices.The 1/3.06-inch OV13850 supports an active array of 4224 x 3136 pixels (13.2-megapixels) operating at30 frames per second (fps) for zero shutter lag and can seamlessly transition between recording video and capturing still images. Additionally, the sensor supports 4K2K ultra-high definition video at 30 fps with full-horizontal field of view (FOV) and electronic image stabilization (EIS), as well as high frame rate 1080p HD video at 60 fps with EIS to enable high quality videos.
Specification
|
Module No |
SNS-113128-V1.1 |
|
Pixel Size |
3.75μm x 3.75μm |
|
Effective Pixels |
13MP 4224(H) x 3136(V) |
|
Video output |
Raw Bayer10bit/8bit |
|
Active Array Size Video Rate |
Full resolution@30FPS,1080P@60FPS |
|
Sensor Type |
Omnivision OV13850 |
|
Lens view |
FOV90°(optional),F/N(optional) |
|
TV Distortion |
<1% |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Operating voltage |
AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V |
|
Operating temperature |
0～60℃ |
|
Storage temperature |
-20～70℃ |
|
Dimensions |
Customizable |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
FAQ:
Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.
Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.
Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.
Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.
Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
