Full HD Camera Module 2MP 60fps Mipi Low Light Performance
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | ROHS |
| Model Number: | SNS-F37-1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | 1/3" F37 |
|---|---|---|---|
| Resolution: | 2MP 1928H X 1088V | Dimensions: | Customizable |
| Lens FOV: | 80°(optional) | Focus Type: | Fixed Focus |
| Interface: | MIPI | Feature: | Full HD |
| High Light: | 2MP 60fps Mipi Camera Module,2MP 60fps Full HD Camera Module,ROHS Mipi Camera Module |
||
Product Description
ROHS Full HD 2MP 60fps Mipi Camera Module Low Light Performance
Full HD Mipi Camera Module 2MP 60fps Low Light Performance
Specification:2MP 60fps Full HD Mipi Camera Module
Model No | SNS-F37-1.0 |
Sensor | 1/2.8’’ F37 |
Pixel | 2 Mega Pixel |
Most effective pixels | 1920(H) x 1080(V) |
Pixel Size | 2.7 x 2.7 µm |
Image area | 1928H x 1088V |
Compression format | MJPEG / YUV2/H.264 |
Resolution & Frame rate | 1920 x1080 @ 60fps |
Shutter Type | Electronic rolling shutter |
Focus type | Fixed focus |
S/N ratio | 52dB |
Dynamic range | 72dB |
Sensitivity | 7757 mV / lux-sec |
Dimension | Customization |
Storage temperature | -20°C to 70°C |
Operating temperature | 0°C to 60°C |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
FAQ:
Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.
Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.
Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.
Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.
Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
