Nintendo Switch 2 camera module GC2053 1080p Personal Privacy Protection with Active Shut-Off Function and Clear Image

Nintendo Switch 2 camera module GC2053 1080p Personal Privacy Protection with Active Shut-Off Function and Clear Image

Place of Origin:

China

Brand Name:

Sinoseen

Certification:

RoHS、ISO9001、CE

Model Number:

xls-1080p-GC2053

Contact Us
Request A Quote
Product Details
Type::
USB Camera Module
Sensor::
GC2053
Resolution::
1920*1080
Dimensions::
Customizable
Lens FOV::
70°(optional)
Focus Type::
Manual Focus
Interface::
USB
Feature::
1080P
Payment & Shipping Terms
Minimum Order Quantity
5
Price
negotiable
Packaging Details
Tray+Anti-static bag in carton box
Delivery Time
2-3week
Payment Terms
T/T
Supply Ability
500000 pieces/month
Product Description
Nintendo Switch 2 Camera Module GC2053
1080p Personal Privacy Protection with Active Shut-Off Function and Clear Image
Product Attributes
Attribute Value
Type USB Camera Module
Sensor GC2053
Resolution 1920*1080
Dimensions Customizable
Lens FOV 70° (optional)
Focus Type Manual Focus
Interface USB
Feature 1080P
Product Description

This USB camera specially designed for Switch 2 offers outstanding imaging performance and user-friendly features, providing a high-definition and smooth video experience. Whether for video calls, live streaming, or capturing moments, it handles all tasks with ease, making interactions clearer and more natural.

The camera is equipped with the GC2053 sensor, delivering full HD resolution of 1920x1080 for rich picture details and true colors. It supports manual focusing for precise clarity adjustment to achieve optimal visual effects. The module supports video recording in MP4 format and image capture in JPG format to meet diverse recording requirements.

Privacy protection is prioritized with an active shut-off function, allowing you to disable the camera at any time. In low-light conditions, three touch-controlled lighting devices provide adjustable illumination for clear, bright images in any lighting environment.

The integrated high-sensitivity microphone ensures clear voice input for both voice chatting and recording. With a signal-to-noise ratio of 39dB and wide dynamic range of 76dB, the module excels in complex lighting conditions while maintaining excellent image quality.

Technical Specifications
SENSOR GC2053
Most effective pixels 1920×1080
Data Format video: MP4, picture: JPG
S/N 39dB
Dynamic range 76dB
Lens FOV 80°
Optical length 4.15mm
Lens construction 2G2P
Mount M6*P0.35mm
Focusing Manual focusing
Frame rate 30fps
Auto control Saturation, Contrast, Acutance, White balance, Exposure
Voltage DC 5V
Backlight lamp Three levels of backlighting with touch control and variable intensity adjustment
Working current MAX 2000mA
USB Connector USB 2.0
Storage Temperature -20℃ to +75℃
Working Temperature 0℃ to +70℃
System compatibility
  • Windows XP(SP2,SP3), Vista, 7, 8, 10
  • Linux or OS with UVC driver
  • iOS
