Effortlessly Capture Stunning Images with the Sinoseen 4152 x 3062 Camera Module imx377 Perfect for Small Portable Devices
Product Details:
Place of Origin: | Shenzhen,China |
Brand Name: | Sinoseen |
Certification: | RoHS |
Model Number: | SNS-GM1104-V1.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 3 |
---|---|
Price: | negotiable |
Packaging Details: | Tray+Anti-static bag in carton box |
Delivery Time: | 2-3weeks |
Payment Terms: | T/T |
Supply Ability: | 500000 pieces/month |
Detail Information |
|||
Type: | MIPI Camera Module | Sensor: | IMX377 1/2.3 Inch |
---|---|---|---|
Resolution: | 12MP 4000*3000 | Dimensions: | Customizable |
EFL: | 4.3 | Lens FOV: | 85° |
Interface: | MIPI |
Product Description
The Sinoseen SNS-GM1104-V1.0 Camera Module delivers uncompromising imaging performance for small portable devices with its:
- Ultra-compact design perfect for action cameras and smart security systems
- 12MP IMX377 CMOS image sensor with 4152 x 3062 effective pixels
- 1/2.3-inch optical format for excellent image quality in miniaturized modules
- MIPI data interface for high-speed, low-power data transmission
Attribute | Value |
---|---|
Type | MIPI Camera Module |
Sensor | IMX377 1/2.3 inch |
Resolution | 12MP 4000*3000 |
Dimensions | Customizable |
EFL | 4.3 |
Lens FOV | 85° |
Interface | MIPI |
Module | SNS-GM1104-V1.0 |
Sensor | IMX377 CMOS |
Image sensor size | 1/2.3 inch |
Pixel | 12MP |
Most effective pixels | 4000*3000 |
Pixel Size | 1.55um*1.55um |
Image sensor Data output | RAW Data 10bits |
Storage temperature | -20°C to 70°C |
Operating temperature | 0°C to 60°C |
Support OS | WinXP/Vista/Win7/Win8/Win10, Linux (above 2.6.26), MAC-OS X 10.4.8+, Android 4.0+ |
This high-performance camera module solves the challenge of limited image quality in small devices, delivering richly detailed, clear images even in challenging environments. Its MIPI interface ensures stable, reliable performance for products with strict battery life and space requirements.
Ideal for portable devices requiring beyond-expectation imaging results, the Sinoseen SNS-GM1104-V1.0 combines miniaturization with professional-grade image capture capabilities.
