High-Speed OV9281 CMOS Camera Module 120FPS 14 Inch 1280x800 USB2.0 Global Shutter Sensor for AI Vision and Industrial Applications
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-SM1159-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | 10-100USD、negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3week |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Stable Temperature: | 0°C To 50°C | Dsp: | USB2.0 DSP |
|---|---|---|---|
| Data Storage: | Video, Pictures | Precision: | ≥5mil |
| Standard Configuration: | USB3.0 High Speed | Chip Type: | OV5648 |
| Image Resolution: | 640*480 | Image Sensor: | CMOS |
| Keywords: | IP Camera Module | Distortion: | ＜22% |
| Interface: | USB | Gpu: | Mali-T860 |
| Max Pixel Rate: | 28Mp/s | Snr: | ≥50db |
| Sensor Type: | CMOS | ||
| Highlight: | OV9281 CMOS camera module with global shutter,USB2.0 camera module 120FPS for AI vision,14 inch industrial camera module 1280x800 |
||
Product Description
High-Speed OV9281 CMOS Camera Module
120FPS 1/4 Inch 1280x800 USB2.0 Global Shutter Sensor for AI Vision and Industrial Applications
The OV9281 CMOS camera module combines high-speed performance and precision imaging in a compact form. Featuring a 1/4-inch CMOS sensor with 1280x800 resolution and 120fps frame rate, it provides crisp, smooth, and distortion-free visuals for machine vision, automation, and AI projects.
This module supports MJPG/YUV video output and Raw 10-bit data, ensuring accurate color and brightness control. The USB2.0 plug-and-play interface allows quick integration and stable data transmission, while compatibility with Windows, Linux, and Android systems offers flexible deployment.
Engineered for industrial, educational, and embedded AI systems, the OV9281 module performs reliably even in low-light conditions, delivering clear and noise-free imagery. Its global shutter ensures accurate motion capture for robotics and inspection applications.
Key Features
- 1280 * 800 resolution, 120fps high frame rate
- Global shutter for precise motion imaging
- Plug-and-play USB2.0 connection
- Supports Raw Bayer and MJPG/YUV output
- Excellent low-light imaging and color accuracy
- Ideal for AI vision, robotics, automation, and industrial use
Technical Specifications
| Signal | SNS-SM1159-V1.0 | Remarks |
|---|---|---|
| Image Sensor Size | 1/4 inch | |
| Effective Pixels | 1280H*800V | |
| Pixel size | 3 um*3 um | |
| Optical distortion | <-1.2% | |
| Image sensor Data output | Raw Bayer 10bits | |
| Video output | MPJG/YUV | |
| Maximum Frame Rates | 2560*800 120FPS 1280*800 120FPS 1280*792 120FPS 2560*720 120FPS 1280*720 120FPS 1280*712 120FPS 1600*600 120FPS 800*600 120FPS 800*592 120FPS 1280*480 210FPS 640*472 210FPS 1280*400 210FPS 640*400 210FPS 640*392 210FPS 640*480 210FPS 640*240 210FPS 320*240 210FPS 320*232 210FPS |
|
| Digital interface | USB2.0 | Cable length 1.5m |
| Transfer rates | 480MB/S | |
| Power requirements | 5V±5% | |
| Storage temperature | -20℃ to 70℃ | |
| Operating temperature | -10℃ to 60℃ | |
| Supported OS | Windows XP/Vista/7/8.1/10/Mac/Android/Linux 2.6.2 (include UVC) | |
| Lens view | M12*P0.5 | LENS |
| Lens Construction | 1G5P+650IR | |
| F/NO aperture | 2.4±5% | |
| EFL effective focal length | 2.6 mm±5% | |
| FOV angle | D: 83°±3° | |
| Focus method | Fixed focus | |
| Shooting distance | 60cm-∞ |
