OV9281 120FPS High-Speed CMOS Sensor USB Camera Module 1/4 Inch 1280x800 for Robotics Machine Vision AI
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-SM1159-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | 10-100USD、negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3week |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Stable Temperature: | 0°C To 50°C | Dsp: | USB2.0 DSP |
|---|---|---|---|
| Data Storage: | Video, Pictures | Precision: | ≥5mil |
| Standard Configuration: | USB3.0 High Speed | Chip Type: | OV5648 |
| Image Resolution: | 640*480 | Image Sensor: | CMOS |
| Keywords: | IP Camera Module | Distortion: | ＜22% |
| Interface: | USB | Gpu: | Mali-T860 |
| Max Pixel Rate: | 28Mp/s | Snr: | ≥50db |
| Sensor Type: | CMOS | ||
| Highlight: | OV9281 USB camera module 120FPS,high-speed CMOS sensor USB camera,USB camera module for robotics |
||
Product Description
OV9281 120FPS High-Speed CMOS Sensor USB Camera Module
The OV9281 CMOS sensor module is a professional imaging solution built for speed, precision, and versatility. Its 1/4-inch CMOS sensor captures sharp 1280x800 resolution images at up to 120fps, ensuring real-time imaging for robotics, AI vision, and industrial inspection systems.
This camera supports MJPG/YUV video output and 10-bit Raw Bayer data, making it adaptable to a wide range of machine vision applications. The USB2.0 interface ensures fast, stable data transfer with true plug-and-play convenience.
Thanks to its global shutter and low-light optimization, the OV9281 delivers consistent brightness and clarity even under challenging lighting conditions. It is compatible with Windows, Linux, Mac, and Android systems, making it an excellent choice for developers and engineers.
Key Features
- 1/4" OV9281 CMOS sensor, 1280 *800 resolution
- 120fps frame rate with global shutter
- USB2.0 high-speed transmission, plug and play
- Excellent low-light sensitivity and dynamic range
- Perfect for AI vision, robotics, and machine inspection
- Reliable, compact, and ready for integration
Technical Specifications
| Signal | SNS-SM1159-V1.0 | Remarks |
|---|---|---|
| Image Sensor Size | 1/4 inch | |
| Effective Pixels | 1280H*800V | |
| Pixel size | 3 um*3 um | |
| Optical distortion | <-1.2% | |
| Image sensor Data output | Raw Bayer 10bits | |
| Video output | MPJG/YUV | |
| Maximum Frame Rates | 2560*800 120FPS 1280*800 120FPS 1280*792 120FPS 2560*720 120FPS 1280*720 120FPS 1280*712 120FPS 1600*600 120FPS 800*600 120FPS 800*592 120FPS 1280*480 210FPS 640*472 210FPS 1280*400 210FPS 640*400 210FPS 640*392 210FPS 640*480 210FPS 640*240 210FPS 320*240 210FPS 320*232 210FPS |
|
| Digital interface | USB2.0 | Cable length 1.5m |
| Transfer rates | 480MB/S | |
| Power requirements | 5V±5% | |
| Storage temperature | -20℃ to 70℃ | |
| Operating temperature | -10℃ to 60℃ | |
| PCB printing ink | Black | |
| Supported OS | Windows XP/Vista/7/8.1/10, Mac, Android, Linux 2.6.2 (include UVC) |
Lens Specifications
| Parameter | Value |
|---|---|
| Default lens | M12*P0.5 |
| Lens Construction | 1G5P+650IR |
| F/NO aperture | 2.4±5% |
| EFL effective focal length | 2.6 mm±5% |
| FOV angle | D: 83°±3° |
| Focus method | Fixed focus |
| Shooting distance | 60cm-∞ |
