CMOS Sensor OV5648 MIPI Camera Module Fixed Focus 2592*1944 Pixels
Product Details:
Place of Origin: | Shenzhen,China |
Brand Name: | Sinoseen |
Certification: | RoHS |
Model Number: | SNS-58875-v1.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 3 |
---|---|
Price: | negotiable |
Packaging Details: | Tray+Anti-static bag in carton box |
Delivery Time: | 2-3weeks |
Payment Terms: | T/T |
Supply Ability: | 500000 pieces/month |
Detail Information |
|||
Type: | MIPI Camera Module | Sensor: | 1/4" Omnivision OV5648 |
---|---|---|---|
Resolution: | 5MP 2592x1944 | Dimensions: | Customizable |
Lens FOV: | 65° | Focus Type: | Fixed Focus |
Interface: | MIPI | Feature: | HD |
Highlight: | 2592*1944 MIPI camera module,OV5648 MIPI camera module,5MP cmos camera module |
Product Description
CMOS Sensor OV5648 MIPI Camera Module Fixed Focus 2592*1944 Pixels
Digital HD 5mp Ov5648 Fixed Focus Cmos Sensor MIPI Interface Camera Module
usb camera module 5mp description
This is a hot selling MIPI camera module made with a 5MP sensor OV5648 from Omnivision.OV5648 is a very good sensor with below features:
1.4umx1.4um pixel with OmniBSI+ technology for high performance(high sensotivity,low crosstalk,low noise).
Automatic image control functions:automatic exposure control(AEC),automatic gain control(AGC),automatic white balance(AWB),and automatic black level calibration(ABLC).
Programmable controls for frame rate,AEC/AGC 16-zone size/position/weight control,mirror and flip.cropping,windowing,and panning.
Support for video or snapshot opetations.
Support for LED and flash strobe mode.
Support for internal and external frame synchronization for frame exposure mode.
Support for black sun cancellation.
It widely used in #cellular phones#toys#PC multimedia#digital still cameras
Specification
Pixel Size |
1.4μm x 1.4μm |
Effective Pixels |
2592*1944 |
Image Sensor |
1/4" |
Sensor Type |
OV5648 |
Lens View |
FOV65°(Optional),F/N(Optional) |
TV Distortion |
<1% (Optional) |
Temperature(Operation) |
0~60℃ |
Temperature(Storage) |
-20~70℃ |
Dimension |
18.5*8.5mm (Customizable) |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
FAQ:
Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.
Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.
Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.
Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.
Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
