GC0308 Sensor 0.3MP Infrared Camera Module Low Power Consumption
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHs |
| Model Number: | SNS-11161-V2.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | 1/ 6.5" GalaxyCore GC0308 |
|---|---|---|---|
| Resolution: | 0.3MP (640*480) | Dimensions: | Customizable |
| Lens FOV: | 60°(optional) | Focus Type: | Fixed Focus |
| Interface: | MIPI | Feature: | Low Power Consumption |
| High Light: | 0.3MP MIPI Infrared Camera Module,GC0308 Infrared Camera Module,GC0308 thermal camera module |
||
Product Description
GC0308 Sensor 0.3MP Infrared Camera Module Low Power Consumption
Low Power Consumption 0.3MP MIPI Camera Module With GalaxyCore GC0308 Sensor
GC0308 Camera Module
This is a 0.3MP MIPI camera module with COMS sensor GC0308 from GalaxyCore. GC0308 is a cheap but good sensor, its image performance is very good and stable.
The MIPI camera module we made is used for scanning code applications, of course, you can also use it in other fields. You can customize the size you need, and match any angle lens.
If you have any needs, please contact our engineering team. We will provide you with the most suitable suggestions based on our years of experience.
|
Model No |
SNS-11161-V2.0 |
|
Sensor |
1/ 6.5’’ GalaxyCore GC0308 |
|
Pixel |
0.3 Mega Pixel |
|
Most effective pixels |
640 (H) x 480 (V) |
|
Pixel Size |
3.4µm x 3.4µm |
|
Resolution & Frame rate |
640x480@30fps; 352x288@30fps; 320x240@30fps; 176x144@30fps; 160x120@30fps; |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Fixed focus |
|
S/N ratio |
49dB |
|
Dynamic range |
55dB |
|
Sensitivity |
3300mV/Lux-sec |
|
Lens FOV |
Default 60° (Optional) |
|
Dimension |
Customizable |
|
Storage temperature |
-30°C to 80°C |
|
Operating temperature |
0°C to 60°C |
