1MP 120FPS Fixed Focus OV7251 USB 2.0 Camera Module
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-1MP-OV7251-SJI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | 1MP Camera Module | Sensor: | 1/7.5'' Omnivision OV7251 |
|---|---|---|---|
| Resolution: | 640(H) X 480(V) | Dimensions: | (customizable) |
| Lens FOV: | 80°(optional) | Focus Type: | Fixed Focus |
| Interface: | USB2.0 | Feature: | Low Power Consumption |
| Highlight: | OV7251 USB 2.0 Camera Module,120FPS USB 2.0 Camera Module,1MP OV7251 Camera Module |
||
Product Description
1/7.5 Inch Fixed Focus 1mp 120FPS Usb Camera Module With OV7251 Sensor.
New Style 1mp 120FPS 1/7.5 Inch Fixed Focus Usb Camera Module With OV7251 Sensor.
OV7251 USB 2.0 Camera Module
Features: Size: 1/7.5
The maximum resolution is: 640(H) x 480(V)
Full resolution can reach 120FPS It has the characteristics of low power consumption and high performance, and can have a good image output
| Model No | SNS-1MP-OV7251-SJI |
| Sensor | 1/7.5’’ Omnivision OV7251 |
| Pixel | 0.3 Mega Pixel |
| Most effective pixels | 640(H) x 480(V), 320(H) x 240(V) |
| Pixel Size | 3.0µm x 3.0µm |
| Image area | 1968um(H) x 1488um (V) |
| Compression format | MJPG |
| Resolution & Frame rate | 640x480@120fps; 320x240@200fps |
| Shutter Type | Global Shutter |
| CFA (Chroma) | Mono, Black/White |
| Focus type | Fixed focus |
| S/N ratio | 38dB |
| Dynamic range | 69.6dB |
| Sensitivity | 10800mV / lux-sec |
| Interface type | USB2.0 high speed |
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition//White balance |
| Lens | Focal length: 3.6mm |
| Lens Size: 1/4 inch | |
| FOV: 60° | |
| Thread Size: M12*P0.5 | |
| Audio frequency | Optional |
| Power supply | USB BUS POWER |
| Power consumption | DC 5V, 120mW |
| Main chip | DSP/SENSOR/FLASH |
| Auto Exposure Control (AEC) | Support |
| Auto White Balance (AEB) | Support |
| Auto Gain Control (AGC) | Support |
| Dimension | 38mm*38mm (customizable ) |
| Storage temperature | -30°C to 70°C |
| Operating temperature | 0°C to 60°C |
| USB cable length | Default |
| Support OS | WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
