Product Details:

Place of Origin: Shenzhen,China
Brand Name: Sinoseen
Certification: RoHS
Model Number: SNS-GM1033-V1.0

Payment & Shipping Terms:

Minimum Order Quantity: 3
Price: negotiable
Packaging Details: Tray+Anti-static bag in carton box
Delivery Time: 2-3weeks
Payment Terms: T/T
Supply Ability: 500000 pieces/month
Get Best Price Contact Now

Detail Information

Type: 1MP Camera Module Sensor: Gc1054
Resolution: 1280(H) X 720(V) Dimensions: (customizable)
Max Frame Rate: 30fps Focus Type: Fixed Focus
Interface: USB2.0 Feature: Low Power Consumption
High Light:

720P USB Camera Module

,

FF Value USB Camera Module

,

Cat Eye 720P Camera Module

Product Description

Factory Customized 1MP 720P FF Value USB Camera Module for Cat Eye Camera



USB Camera Module

This is a factory made camera module with gc1054 sensor, the current interface is USB2.0. This is a good value and cheap module. At present, smartphones generally use 720P resolution screens. We know that the higher the screen resolution, the better the picture quality displayed. 720P is a mid-to-high-end screen. The picture quality of the display screen has reached very clear, usually only the popular mainstream mobile phone screen reaches 720P resolution, also known as standard definition, this module is widely used in mainstream LCD monitors, LCD TVs and mobile phone screen parameters. So this product is also a good choice.


Specification
Parameter Typical value
Active pixel array 1280*720
ADC resolution 10bit ADC
Max Frame rate 30fps
Power Supply AVDD:3.15-3.45V(Typ.3.3V)
  DVDD:1.4-1.6(Typ.1.5V)
  IOVDD:1.7-3.45V(Typ.1.8V)
Power Consumption 110mW@30fps,720p
SNR TdB
Dart Current 200e-/s(60)
Sensitivity 18000e-/lux-sec
Dynamic range TdB
Operating temperature -30-80
Stable Image temperature -0~60°
Optimal Lens chief ray angle(CRA) 12(linear)
Package type CSP/PLCC
