Place of Origin:
Shenzhen,China
Brand Name:
Sinoseen
Certification:
RoHS
Model Number:
SNS-S101-v1.0
| Parameter | Typical value |
| Active pixel array | 1280*720 |
| ADC resolution | 10bit ADC |
| Max Frame rate | 30fps |
| Power Supply | AVDD:3.15-3.45V(Typ.3.3V) |
| DVDD:1.4-1.6(Typ.1.5V) | |
| IOVDD:1.7-3.45V(Typ.1.8V) | |
| Power Consumption | 110mW@30fps,720p |
| SNR | TdB |
| Dart Current | 200e-/s(60) |
| Sensitivity | 18000e-/lux-sec |
| Dynamic range | TdB |
| Operating temperature | -30-80 |
| Stable Image temperature | -0~60° |
| Optimal Lens chief ray angle(CRA) | 12(linear) |
| Package type | CSP/PLCC |
Shenzhen Sinoseen Technology Co.,Ltd
China top 10 camera module manufacturer
We customize all kinds of USB/MIPI/DVP camera module as per your request
