GC2053 Sensor 1080P 30 Frames 2MP Camera Module Autofocus MIPI Interface
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | XLS21831-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | 2MP Camera Module | Sensor: | 1/2.9'' GC2053 |
|---|---|---|---|
| Resolution: | 1920(H) X 1080(V) | Dimensions: | (customizable) |
| Lens FOV: | 100°(optional) | Focus Type: | AF |
| Interface: | MIPI | Feature: | Low Power Consumption |
| High Light: | MIPI Interface 2MP Camera Module,Autofocus 2MP Camera Module,GC2053 Sensor MIPI Camera Module |
||
Product Description
GC2053 Sensor 1080P 30 Frames 2MP Camera Module Autofocus MIPI Interface
GC2053 Camera Module
The camera module uses a GC2053 image sensor. The GC2053 is a CMOS (Complementary Metal Oxide Semiconductor) sensor with a resolution of 2 megapixels (2MP). It is capable of capturing images with good detail and color accuracy. The camera module supports video recording at a resolution of 1080P (1920 x 1080 pixels) and a frame rate of 30 frames per second. This frame rate enables smooth video playback of real-time motion. The camera module has autofocus functionality. Autofocus enables the camera to automatically adjust focus to ensure clear and sharp images. This feature is particularly useful when capturing subjects at different distances or when the subject is moving. The camera module can be integrated into a variety of devices such as smartphones, tablets, laptops or other electronic devices that require a compact and versatile camera solution.
Specification
| Parameter | Typical value |
| Optical Format | 1/2.9inch |
| Active pixel array | 1920*1080 |
| Pixel Size | 2.8um*2.8um |
| Shutter type | Electonic rolling shutter |
| ADC resolution | 10 bit ADC |
| Max Frame rate | 30fps@full size |
| Power Supply | AVDD28:2.8V |
| DVDD:1.2V | |
| IOVDD:1.8V | |
| Power Consumption | TBD |
| SNR | TBD |
| Dark Current | TBD |
| Sensitivity | TBD |
| Dynamic range | TBD |
| Operating temperature: | -20°C to 80°C |
| Stable Image temperature | 0°C to 60°C |
| Optimal Lens chief ray angle(CRA) | 12(linear) |
| Package type | CSP |
| Input clock frequency | 6-27MHz |
