Name: 5MP MIPI Camera Module OV5648 Sensor 90fps for Mobile Devices
Brand: Shenzhen Sinoseen Technology Co., Ltd
SKU: SNS51867-V1.0
Availability: InStock

Home > products > MIPI Camera Module >

5MP MIPI Camera Module OV5648 Sensor 90fps for Mobile Devices

90fps MIPI Camera Module

Fixed Focus MIPI Camera Module

2592*1944 MIPI Camera Module

Place of Origin:

Shenzhen,China

Brand Name:

Sinoseen

Certification:

RoHS

Model Number:

SNS51867-V1.0

Request A Quote

Product Details

Type:

MIPI Camera Module

Sensor:

OV5648 1/4 Inch

Resolution:

5MP 2592*1944

Dimensions:

Customizable

Frame Rate:

90FPS

Lens FOV:

125°(optional)

Interface:

MIPI

Feature:

Low Crosstalk And Low Noise

Highlight:

90fps MIPI Camera Module

Fixed Focus MIPI Camera Module

2592*1944 MIPI Camera Module

Payment & Shipping Terms

Minimum Order Quantity

Price

negotiable

Packaging Details

Tray+Anti-static bag in carton box

Delivery Time

2-3weeks

Payment Terms

T/T

Supply Ability

500000 pieces/month

IMX307 1080P MIPI Camera Module 60FPS for Smart Home and Drone

Get Best Price

VB1940 MIPI Camera Module 5.1MP Global Shutter for Automotive

Get Best Price

AR2020 20MP MIPI Camera Module for Industrial Machine Vision

Get Best Price

S5K3P3SX 16MP MIPI Camera Module for Smart Home and Drones

Get Best Price

Contact Now

Product Description

5MP MIPI Camera Module OV5648 Sensor 90fps for Mobile Devices

Key Features

5MP resolution (2592×1944 pixels)
High frame rate of 90fps for smooth video
OV5648 CMOS sensor with OmniBSI+ technology
MIPI interface for high-speed data transmission
Low crosstalk and low noise performance
Fixed focus lens for clear images
Wide 125° field of view (optional)

Product Specifications

Attribute	Value
Type	MIPI Camera Module
Sensor	OV5648 1/4 inch
Resolution	5MP 2592×1944
Dimensions	Customizable
Frame Rate	90FPS
Lens FOV	125° (optional)
Interface	MIPI

Technical Details

Module	SNS51867-V1.0
Sensor	OV5648 CMOS
Pixel Size	1.4μm×1.4μm
Focus Type	Fixed focus
Output Interface	2-lane MIPI
Output Formats	8/10-bit RGB RAW
Shutter Type	Rolling shutter
Max S/N Ratio	34dB
Operating Temperature	0°C to 60°C
Storage Temperature	-20°C to 70°C

Performance Specifications

Max Image Transfer Rate: QSXGA:15fps, 1080p:30fps, 960p:45fps, 720p:60fps, VGA:90fps

Supported Operating Systems

Windows XP/Vista/7/8/10, Linux (kernel 2.6.26+), Mac OS X 10.4.8+, Android 4.0+

Product Description

This high-performance camera module is specifically designed for smartphones and tablets, delivering excellent image quality with advanced features for diverse applications. The 5MP resolution (2592×1944 pixels) ensures clear, detailed images, while the 90fps frame rate enables smooth video recording and playback.

The module features Omnivision's OV5648 CMOS sensor with OmniBSI+ technology, offering high sensitivity, low crosstalk, and low noise performance. The fixed-focus lens guarantees consistently sharp images, and the MIPI interface provides high-speed data transmission optimized for mobile devices.

Applications

High-quality mobile photography
HD video recording on smartphones and tablets
Video conferencing with clear, smooth streaming
Mobile device imaging solutions

Product Images
