OV9281 MIPI Camera Module 1MP 120FPS for Smart Transportation
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS11874-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | MIPI Camera Module | Sensor: | OV9281 1/4 Inch |
|---|---|---|---|
| Resolution: | 1MP 1280*800 | Dimensions: | Customizable |
| Frame Rate: | 120FPS | Lens FOV: | 48°(optional) |
| Interface: | MIPI | Feature: | Low-light Sensitivity And Achieves High-quality Imaging |
| Highlight: | OV9281 MIPI camera module 1MP,MIPI camera module 120FPS,smart transportation camera module |
||
Product Description
| Attribute | Value |
|---|---|
| Type | MIPI Camera Module |
| Sensor | OV9281 1/4 inch |
| Resolution | 1MP 1280*800 |
| Dimensions | Customizable |
| Frame Rate | 120FPS |
| Lens FOV | 48° (optional) |
| Interface | MIPI |
| Feature | Low-light sensitivity and achieves high-quality imaging |
This compact camera module is built to support smart transportation, AI recognition, and machine vision applications. With its global shutter and 120fps high frame rate, it delivers crisp, distortion-free imaging for fast-moving objects such as vehicles or hand gestures.
The 1280 × 800 resolution, combined with excellent low-light performance, makes it a solid fit for environments like traffic intersections, gesture-controlled UIs, or factory inspection lines. The fixed-focus lens guarantees consistent clarity, and its MIPI interface ensures seamless integration into embedded systems.
- Traffic Monitoring & LPR - Sharp images of fast-moving vehicles
- Gesture Interaction - For kiosks, smart retail, or automotive HMI
- Industrial Inspection - Detect product defects at production speeds
Supported platforms include Jetson Nano, Android boards, and Raspberry Pi CM4.
| Module | SNS11874-V1.0 |
|---|---|
| Sensor | OV9281 CMOS |
| Pixel | 1MP |
| Most effective pixels | 1280*800 |
| Pixel Size | 3um*3um |
| Frame rate | 120fps |
| Focus type | Fixed focus |
| Output interface | 2-lane MIPI |
| Output formats | 10-bit RAW |
| Max S/N ratio | TBD |
| Dynamic | TBD |
| Storage temperature | -20°C to 70°C |
| Operating temperature | 0°C to 60°C |
| Support OS | WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
Looking for a specific lens angle? Need to adjust form factor or frame rate?
We provide flexible OEM/ODM customization:
- Lens FOV tuning for traffic, face, or hand detection
- Compact board re-design for space-constrained applications
- Sensor swap or interface adaptation
Let us help you bring your vision project to life — quickly and efficiently.
At Sinoseen, we focus on delivering high-performance vision modules that meet the evolving needs of industries like security, automation, AI, and smart retail. Since 2016, we have served hundreds of global clients with tailored camera solutions.
We value transparency, quality, and long-term partnerships.
