Laptop Color Camera Module OV5648 Sensor 5MP USB Auto Focus Camera Module
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-DZ1018-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | USB Camera Module | Sensor: | 1/4"Omnivision OV5648 |
|---|---|---|---|
| Resolution: | 5MP (2592*1944) | Dimensions: | Customizable) |
| Shutter: | Roller Shutter | Focus Type: | Auto Focus |
| Interface: | USB2.0 | Feature: | HD |
| High Light: | DVP Color Camera Module,OV5648 Sensor Color Camera Module,USB2.0 Auto Focus Camera Module |
||
Product Description
Color OV5648 Sensor 5MP MIPI Auto Focus Camera Module Laptop
5MP autofocus camera module
This is a Color 5 megapixel image camera module. Usually used in camera modules of smartphones, laptops and other devices. It supports 1080p video recording and has an autofocus function that allows the camera to automatically adjust the focus for the best image quality.
In the context of a laptop camera module, the OV5648 sensor with MIPI interface and autofocus can provide high-quality video conferencing and image capture. It is often combined with other components such as lenses and image processing chips to create a complete camera module that can be integrated into a laptop or other device.
Specification
|
Model No |
SNS-DZ1018-V1.0 |
|
Sensor |
1/4’’ Omnivision OV5648 |
|
Pixel |
5 Mega Pixel |
|
Most effective pixels |
2592(H) x 1944(V) |
|
Pixel Size |
1.4µm x 1.4µm |
|
Image area |
3673.6µm x 2738.4µm |
|
Compression format |
MJPG/YUY2 |
|
Resolution & Frame rate |
See above |
|
Shutter Type |
Electronic rolling shutter |
|
Focus type |
Auto Focus |
|
S/N ratio |
36dB |
|
Dynamic range |
72 dB @ 8x gain |
|
Sensitivity |
690mV / lux-sec |
|
Interface type |
USB2.0 high seepd |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/ |
|
Audio frequency |
Optional |
|
Power supply |
USB BUS POWER |
|
Power consumption |
DC 5V, 200mW |
|
Main chip |
DSP/SENSOR/FLASH |
|
Auto Exposure Control (AEC) |
Support |
|
Auto White Balance (AEB) |
Support |
|
Auto Gain Control (AGC) |
Support |
|
Operating temperature |
30°C to 70°C |
|
USB cable length |
Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10 |
