OEM Customizable Medical Endoscope USB Camera Module Vision Solution
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-1MP-OV9734-S2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Type: | USB Camera Module | Sensor: | 1/9" Omnivision OV9734 |
|---|---|---|---|
| Resolution: | 1MP 1280(H) X 720(V) | Dimensions: | Customizable |
| Lens FOV: | 60°(optional) | Focus Type: | Fixed Focus |
| Interface: | USB2.0 | Feature: | Endoscope Camera Module |
| High Light: | Omnivision OV9734 USB Camera Module,Medical Endoscope OEM Camera Modules,Vision Solution OEM Camera Modules |
||
Product Description
Medical Endoscope OEM Camera Modules Vision Solution OV9734 Sensor
OEM Customizable Medical Endoscope USB Camera Module Vision Solution
This is a camera module specially designed for medical endoscopy applications. It's a USB camera module, which means it can be connected directly to a computer or other device with a USB port.
This camera module can be customized to meet the specific needs of medical endoscopy applications. It features high-quality optics and image sensors that deliver high-resolution images and video. The camera module can be integrated with various endoscopes and can be customized according to the specific requirements of the endoscope.
A USB interface allows easy connection to computers and other devices, and the camera module can be controlled using the software provided with the module. This allows for easy capture and analysis of images and videos.
| Module No | SNS-1MP-OV9734-S2 |
| Pixel Size | 1.4μm x 1.4μm |
| Effective Pixels | 1MP 1280(H) x 720(V) |
| Video output | Raw Bayer10bit/8bit |
| Active Array Size Video Rate | 30FPS |
| Image Sensor | 1/9" |
| Sensor Type | Omnivision OV9734 |
| Lens view | FOV60°(optional),F/N(optional) |
| TV Distortion | <1% |
| AEC | Support |
| AEB | Support |
| AGC | Support |
| Operating voltage | AVDD:3.0~3.6V DOVDD:1.7~3.6V DVDD:1.7~1.9V |
| Operating temperature | -20～70℃ |
| Storage temperature | 0～50℃ |
| Dimensions | Customizable |
