Sinoseen DVP Camera Module The Perfect Choice for Battery-Powered Devices and Low-Light Conditions
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS21816-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3week |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
|
Detail Information |
|||
| Sensor: | 1/2.9 | Sensor Type: | CMOS |
|---|---|---|---|
| Noise: | >42db (AGC OFF) | Image Area: | 3896 μm X 2453 μm |
| Lens Mount: | CS-Mount | Array Size: | 1600*1200 |
| Assembly Technique: | SMT (ROSH) | Module Size: | 38mm×38mm（±1mm) |
| Shutter Type: | Global Shutter | Power Consumption: | 1.5W |
| Frame Rate: | 30fps | Pixel: | 2MP Color Global Shutter Camera Module |
| General: | -20---70°C | Pinout: | 24pin |
| Focus Type: | Fixed Focus | ||
Product Description
Sinoseen DVP Camera Module - The Perfect Choice for Battery-Powered Devices and Low-Light Conditions
Key Specifications
| Sensor | 1/2.9 |
|---|---|
| Sensor Type | CMOS |
| Noise | >42db (AGC OFF) |
| Image Area | 3896 μm x 2453 μm |
| Lens Mount | CS-Mount |
| Array Size | 1600*1200 |
| Assembly Technique | SMT (ROSH) |
| Module Size | 38mm×38mm（±1mm) |
| Shutter Type | Global Shutter |
| Power Consumption | 1.5W |
| Frame Rate | 30fps |
| Pixel | 2MP Color Global Shutter Camera Module |
| Operating Temperature | -20°C to 70°C |
| Pinout | 24pin |
| Focus Type | Fixed focus |
Product Highlights
The Sinoseen GC2053 1080P CMOS Image Sensor delivers exceptional performance for battery-powered devices operating in low-light conditions. With its 1920 x 1080 Full HD resolution and advanced image processing, this sensor captures sharp, detailed images even in challenging lighting environments.
- Ultra-low power consumption (98mW) extends battery life for sports cameras and dashcams
- Global shutter technology ensures crisp image capture of moving objects
- 30fps frame rate at full resolution for smooth video capture
- Supports RAW10/RAW8 data formats for flexible integration
- Compatible with MIPI/DVP interfaces for versatile applications
- Ideal for security surveillance and consumer electronics
This compact camera module (38mm × 38mm) features a CS-mount lens system and SMT assembly technique, making it suitable for space-constrained applications while meeting ROHS compliance standards.
